creati0n
unable to receive led response from Quneo .. any ideas/suggestions appreciated
I created the Generic Midi device xml :
<?xml version="1.0" encoding="UTF-8"?>
<device author="Atomix Productions" name="SIMPLE_MIDI"
sysexid="F07E00060200015F1E00000003010211F7" type="MIDI" decks="2" >
<button note="2-16" name="play" channel="2" deck="1"/>
<led note="2-16" name="led_play" default="play" channel="2" deck="1"/>
</device>
and here is the default Generic Midi mapping xml :
<?xml version="1.0" encoding="UTF-8"?>
<mapper device="SIMPLE_MIDI" author="Atomix Productions"
description="Simple MIDI wrapper" version="720" date="04/11/2012"
priority="-10">
<map value="2-16" action="play" />
</mapper>
I created the Generic Midi device xml :
<?xml version="1.0" encoding="UTF-8"?>
<device author="Atomix Productions" name="SIMPLE_MIDI"
sysexid="F07E00060200015F1E00000003010211F7" type="MIDI" decks="2" >
<button note="2-16" name="play" channel="2" deck="1"/>
<led note="2-16" name="led_play" default="play" channel="2" deck="1"/>
</device>
and here is the default Generic Midi mapping xml :
<?xml version="1.0" encoding="UTF-8"?>
<mapper device="SIMPLE_MIDI" author="Atomix Productions"
description="Simple MIDI wrapper" version="720" date="04/11/2012"
priority="-10">
<map value="2-16" action="play" />
</mapper>
Posted Fri 09 Nov 12 @ 6:59 pm
creati0n
Ok so I did however try using both Simple Midi AND Quneo named files.
"Simple MIDI Wrapper only supports very basic MIDI mapping. Mapping LED's is not possible"
Whenever I save the definition file to /device I lose the simple midi wrapper and lose the ability to use the controller at all.
So I can use the Simple Midi to use the controller, just unable to configure/create .xml files properly to receive LED.... again any help appreciated.
"Simple MIDI Wrapper only supports very basic MIDI mapping. Mapping LED's is not possible"
Whenever I save the definition file to /device I lose the simple midi wrapper and lose the ability to use the controller at all.
So I can use the Simple Midi to use the controller, just unable to configure/create .xml files properly to receive LED.... again any help appreciated.
Posted Tue 13 Nov 12 @ 11:13 pm
creati0n
anybody ... (crickets)
Posted Mon 26 Nov 12 @ 6:37 pm
PhantomDeejay
Try this:
<?xml version="1.0" encoding="UTF-8"?>
<device name="QUNEO" description="QUNEO Midi" author="PhantomDj" type="MIDI" sysexid="F07E00060200015F1E00000003010211F7" decks="2" version="730">
<button note="0x64" channel="1" deck="1" name="PLAY"/>
<led note="0x64" channel="1" deck="1" name="LED_PLAY" default="PLAY"/>
<button note="0x24" channel="1" deck="2" name="PLAY"/>
<led note="0x24" channel="1" deck="2" name="LED_PLAY" default="PLAY"/>
</device>
Some notes:
1) You must convert named notes to their HEX value
2) Ch1 of your controller is CH0 for VDJ. Thus Ch2 of your controller is CH1 for VDJ
<?xml version="1.0" encoding="UTF-8"?>
<device name="QUNEO" description="QUNEO Midi" author="PhantomDj" type="MIDI" sysexid="F07E00060200015F1E00000003010211F7" decks="2" version="730">
<button note="0x64" channel="1" deck="1" name="PLAY"/>
<led note="0x64" channel="1" deck="1" name="LED_PLAY" default="PLAY"/>
<button note="0x24" channel="1" deck="2" name="PLAY"/>
<led note="0x24" channel="1" deck="2" name="LED_PLAY" default="PLAY"/>
</device>
Some notes:
1) You must convert named notes to their HEX value
2) Ch1 of your controller is CH0 for VDJ. Thus Ch2 of your controller is CH1 for VDJ
Posted Tue 27 Nov 12 @ 3:41 am
